Hexagonal Design C16 | Two- to Six-Finger Hollow Gripper

Characteristics

• centric, linear and parallel or swiveling, finger movement; can also be combined
• variable length, number and position of fingers
• inside and outside gripping applications
• lubrication- and maintenance-free slide bearings
• continuous hollow center (Ø80mm)
• no self-lock
• continuously adjustable stroke with end position damping on both sides, or
• object retention upon loss of air pressure through gas springs (optional)
• multiple position checks through proximity switches (optional)

Technical Datasheet
Spare Part List
Operating Instruction

For planners: Step files of the C16 are available on

Finger Movement A

Finger Movement B

Finger Movement C
