Finger Movement CP | Swiveling Movement with Parallel Guided Top Jaws
Characteristics
- sviweling movement of fingers with continuously parallel guided top jaws
- available for all hexagonal and rectangular grippers
- universal top jaws at the fingertips
- customized top jaws available on request
- variable length, number, and position of fingers
- inside and outside gripping applications
- lubrication- and maintenance-free slide bearings
- continuous hollow center (starting at size 06)
- no self-lock
- continuously adjustable stroke with end position damping on both sides, or
- object retention upon loss of air pressure through gas springs (optional)
Download
For planners: Step files of the hexagonal gripper types with finger movement CP are available on
